Detail Indikator / Loadcell Digital

MKCells MK-SLB-D

FEATURES : MKCELLS MK-SLB-D DIGITAL LOAD CELL

High accuracy High quality shear beam load cell Nickel plated steel with anti corrosive Standard leveling foot for universal application Can use for forklift, pallet, silo, hopper, low platform scale Compatible with all MK Digital Indicator

SPECIFICATIONS : MKCELLS MK-SLB-D DIGITAL LOAD CELL

Rated capacities (Emax) 0.25, 0.5, 1, 2, 3,5,10t Temperature, operating -30°C~+70°C Rated output 250, 500, 1000, 2000, 3000, 5000, 10000 Maximum safe overload 150%F.S Combine error ±0.02% F.S Ultimate overload 180%F.S Zero balance ±0.1%F.S Excitation, recommended 10-12V DC Creep (30 min) ±0.02%F.S/10°C Excitation, maximum 20 VDC TC SPAN ±0.02%F.S/10°C Protection class IP68 Communication Baud rate 9600 Bps Construction Nickel Plated Steel Data refresh frequency 50 Hz Cable Length 3m(0.25-2t), 4.2m(3-5t), 5m(10t) Temperature, compensated -10°C ~ +40°C Diameter Φ 5mm
