Detail Digital Indikator Mkcell Untuk Jembatan Timbang

MKCells MK-Di02

MKCells MK-Di02 Digital weighing indicator can be used with 1 – 4 SLB-D or digital load cell. It has the function of accumulation and unit switch over and applies to small platform scale, weighbridge and farmers scale.



Characteristic and functions:



Plastic housing

Calibration switch code

Support regular shutdown, random code decryption function

Input password before calibration and adjusting

Auto networking and auto auto-creating weighing scale system

Automatic and manual corner-difference adjustment

Power on, auto zero-setting range, manual zero-setting range can be set separately, zero tracing range can be set

Random charging by indicator

RS232 communication interface, multi communication protocol

Encryption function is available while load cell and indicator is communicating

Digital load cell SN checking, overload record checking function

Equipped with EMC protection

Main Technical Parameters Digital load cell interface RS485, max transmission distance ≤ 75m Transmission speed rate 19200 bps Digital load cell power supply DC 12V/750mA Digital load cell connection quantity 1 ~ 4 pcs Digital load cell communication protocol MK-SLB-D protocol Display 6 LED digital tube with 1.2 inch red light, 7 state instruction Serial communication interface RS232, 600 ~ 19200 bps optional Indicator power supply AC : Switch power supply 110V ~ 200V/AC, 50Hz Operating temperature 0°C ~ 40°C Humidity : £ 85% (RH) Storage temperature -10°C ~ 60°C Storage Humidity : £ 95% (RH)
